Honeywell Voyager XP 14XX Setup

Honeywell Voyager XP 14XX Setup

The Honeywell 1450/1452 and 1470/1472 series scanners can be programmed by scanning the barcodes found below.

Function
Barcode
Reset All Defaults
Reset All Defaults
USB Serial (COM) Emulation

USB Keyboard Wedge
USB Keyboard
Add CR Suffix
Add CR Suffix
Remove Suffix
Remove Suffix
Revision Information - Print out scanner information, best used in keyboard wedge mode.
Turn off presentation mode

Turn off sleep mode


If you are using the scanner in USB Keyboard Wedge mode, you will need to add the CR suffix in order for product barcodes to be scanned and inputted into GPoS. If you are using the scanner in USB Serial mode, you will need the latest Honeywell Scanning & Mobility drivers which can be found by clicking here or on the Honeywell Downloads Server.

A Reader Peripheral will also need to be configured in GPoS Utility with the correct COM port, so that GPoS knows to use this specific Peripheral for scanning operations. A Reader Peripheral is not required for a scanner in USB Keyboard Wedge mode, as a scanner in this mode just passes all data through to the PC or POS terminal to whichever application is open and in the foreground at the time.

Links to the Quick Start guides for these scanners, which contain the above barcodes along with additional barcodes for other functions, are found below:
