Setting Scanners to be in USB Serial Emulation mode

Setting Scanners to be in USB Serial Emulation mode

Scanners can be operated in USB Serial Emulation mode, which means that the scanner connects to the POS terminal as a virtual serial device. This can be done either with a utility provided by the manufacturer, or by scanning programming barcodes.

Honeywell Fusion MS3780

Barcode Programming

Scan this barcode to enter/exit programming
Scan this barcode to set USB Serial Emulation mode
Honeywell Fusion MS3780 - Barcode Programming USB Serial Emulation
Scan this barcode to set USB Keyboard Emulation mode
Honeywell Fusion MS3780 - Barcode Programming USB Keyboard Emulation
Scan this barcode to recall all defaults and reset to factory settings
Honeywell Fusion MS3780 - Barcode Programming Recall Defaults
